GENERAL APPLICATION DOUBLE RELAY 24V 22A

OE quality multipurpose twin relay with for universal applications

SPECS:
Application: multipurpose

Type: normally open
Volts: 24VDC
Current: 22A
Connections: 8 x 6.3mm
Mounting bracket: Yes
Resistor: No
Diode: No
Note: Two independent relays in one housing

PIN LAYOUT:
PIN CONNECTION
85 Relay coil
86 Relay coil
30 24VDC
87 Output
